VAT 615 Series

Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
603476EA
2013-07-25
26/102
1 (Sensor 1)
2 (Sensor 2)
3 (Position)
14
Gain
Scales pressure ore position values. Gain is only used
if data unit count is selected.
The Electronic Data Sheet (EDS) allows the configuration of DeviceNet
®
components with a general configuration tool.
The EDS contains general data regarding device, selection of operation mode, assignment of I/O data to the
corresponding I/O message connections (Polling, Bit Strobe, Change of State) and description of device parameters.
The parameters of a device are described in a form which is defined by DeviceNet
®
and visualized by a configuration
tool.
Note: EDS can be downloaded on our website: http://www.vat.ch > Select your country > Downloads > EDS Files
4. If Poll or Change of State / Cycling connection is used for remote operation it’s required to preset the correct
assemblies.
Default values are:
poll output assembly = 103
poll input assembly = 106
change of state / cycling input assembly = 106
Assembly object change procedure:
Local operation:
(‘Control View’, ‘Control Performance Analyzer’ or
‘Service Box 2‘)
Remote operation:
(Refer to chapter «Connection object» for details)
Note: It’s not possible to make assembly object
configuration in local operation.
1. Select
POLL CONNECTION OUTPUT
assembly
2. Select
POLL CONNECTION INPUT
assembly
3. Reestablish poll I/O connection
