VAT 615 Series

Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
603476EA
2013-07-25
60/102
Instance
ID
Type
Composition
1)
Start
Byte
Byte
Length
Service
data
length
(number
of bytes
Data
Type
26
Input
EXCEPTION STATUS
FP-PRESSURE
FP-POSITION
VALVE CLOSED / OPEN CHECK
0
1
5
9
1
4
4
1
10
floating point
100
Input
EXCEPTION STATUS
PRESSURE
POSITION
CONTROL MODE
ACCESS MODE
0
1
3
5
6
1
2
2
1
1
7
signed integer
101
Input
EXCEPTION STATUS
PRESSURE
POSITION
VALVE CLOSED / OPEN CHECK
CONTROL MODE
0
1
3
5
6
1
2
2
1
1
7
signed integer
102
Output
CONTROL MODE
PRESSURE / POSITION SETPOINT
2)
SETPOINT TYPE
LEARN
4)
LEARN PRESSURE LIMIT
ZERO
4)
0
1
3
5
6
8
1
2
2
1
2
1
9
signed integer
103
Output
CONTROL MODE
PRESSURE / POSITION SETPOINT
2)
SETPOINT TYPE
INDIVIDUAL CLUSTER CONTROL (ADDRESS)
INDIVIDUAL CLUSTER CONTROL (ACTION)
0
1
3
5
6
1
2
2
1
1
7
signed integer
104
Input
EXCEPTION STATUS
PRESSURE
SENSOR 2 READING
POSITION
ACCESS MODE
CONTROL MODE
CLUSTERINFORMATION (00..13)
3)
0
1
3
5
7
8
9
1
2
2
2
1
1
min. 1
max. 14
min. 10
max. 23
signed integer
105
Input
EXCEPTION STATUS
FP-PRESSURE
FP-POSITION
CONTROL MODE
ACCESS MODE
0
1
5
9
10
1
4
4
1
1
11
floating point
106
Input
EXCEPTION STATUS
FP-PRESSURE
FP-POSITION
VALVE CLOSED / OPEN CHECK
DEVICE STATUS 2
0
1
5
9
10
1
4
4
1
1
11
floating point
107
Output
CONTROL MODE
FP-PRESSURE / POSITION SETPOINT
2)
SETPOINT TYPE
LEARN
4)
FP- LEARN PRESSURE LIMIT
ZERO
4)
0
1
5
7
8
12
1
4
1
1
4
1
12
floating point
108
Output
CONTROL MODE
FP-PRESSURE / POSITION SETPOINT
2)
SETPOINT TYPE
INDIVIDUAL CLUSTER CONTROL (ADDRESS)
INDIVIDUAL CLUSTER CONTROL (ACTION)
0
1
5
7
8
1
4
2
1
1
9
floating point
