VAT 615 Series

Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
603476EA
2013-07-25
72/102
Command
Service Code
Class ID
Instance ID
Attribute ID
Service
data length
(number of bytes)
Service
data field
Description
LEARN STATUS
Get
14
51
1
106
2
This command returns the status of the LEARN procedure. The status is binary coded.
Bit Explanation:
(LSB) 0 0 = LEARN not running
1 = LEARN running
1 0 = LEARN data set present
1 = LEARN data set not present
2 0 = ok
1 = LEARN terminated by user
3 0 = ok
1 = pressure in position OPEN
> 50% sensor full scale (of high range sensor in case of a 2 sensor system)
or
> LEARN PRESSURE LIMIT
4 0 = ok
1 = pressure in position 0
< 10% sensor full scale (of low range sensor in case of a 2 sensor system)
5 0 = ok
1 = pressure falling during LEARN
6 0 = ok
1 = sensor not stable during LEARN
7 reserved
8 reserved
9 reserved
10 0 = ok
1 = LEARN terminated by controller
11 0 = ok
1 = pressure in position OPEN negativ
12 reserved
13 reserved
14 reserved
15 reserved
(MSB) 16 reserved
