Failure
Check
Action
Remote operation (DeviceNet
®
)
does not work
- Local operation via service
port active
- Switch to remote operation.
- Safety mode active, check for
D on display?
- Provide power to motor to allow for operation.
- Refer to «Electrical connection» for details.
Display shows «E 20»
(fatal error - limit stop of valve
unit not detected)
- Clamp coupling screw not
fastened?
- Tighten screw. See chapter «Tightening torque» for details.
Display shows «E 21»
(fatal error - rotation angle of
valve plate limited during power
up)
- Valve plate centric adjusted?
- Adjust valve plate according to
«Maintenance procedures».
- Valve unit heavy
contaminated?
- Clean valve unit according to
«Maintenance procedures».
- Valve plate mechanically
obstructed?
- Resolve obstruction.
Display shows «E 22»
(fatal error - rotation angle of
valve plate limited during
operation)
- Valve unit heavy
contaminated?
- Clean valve unit according to
«Maintenance procedures».
- Valve plate mechanically
obstructed?
- Resolve obstruction.
Display shows «E 40»
(fatal error - motor driver failure
detected)
- Replace control and actuating unit according to
«Maintenance procedures».
Display shows «D999»
- Motor power supplied?
- Provide power to motor to allow for operation.
- Refer to «Electrical connection» for details.
CLOSE VALVE does not work
- Safety mode active, check for
D on display?
- Provide power to motor to allow for operation.
- Refer to «Electrical connection» for details.
OPEN VALVE does not work
- Safety mode active, check for
D on display?
- Provide power to motor to allow for operation.
- Refer to «Electrical connection» for details.
POSITION CONTROL does not
work
- Safety mode active, check for
D on display?
- Provide power to motor to allow for operation.
- Refer to «Electrical connection» for details.
- POSITION CONTROL
selected, check for V on
display?
- Select POSITION CONTROL mode.
Refer to «Position control» for details.
