CTC II The steps involved in measuring and testing
Operating Instructions Rolling road test stand
42 © Continental Trading GmbH A2C59512809
Function Key Action/ Command Value/ Information
Engaging brake
1)
BR = OFF
Releasing brake BR = ON
Correct. value
2)
,
,
Modify correction value and
confirm.
Max. ± 9.9 %
W-Measurem. Drive measuring roller.
Start the menu
3)
.
Characteristic
coefficient "W".
Automatic, acoustic
signal
Stop measuring roller.
K value is adjusted.
Wheel
circumference
Drive measuring roller.
Wheel circumference is
determined.
Acoustic signal
Automatic
measurement
Start the Automatic
measurement menu.
• Wheel circumference
• Characteristic
coefficient "W"
3) 4)
.
Automatic, acoustic
signal
Stop measuring roller.
K value is adjusted. Determined
characteristic
coefficient "W" is
programmed into the
tachograph.
