Verathon Service Partner Manual: Reference Documentation
PART NUMBERS
PART PART NUMBER
Console
Bottom
Bottom cover 0122‑0003
Label
BVI3000 console label, non‑UDI 0125‑0270
BVI3000 console label kit with serial number, UDI‑compliant 0800‑0550
Console foot 0122‑0014
Screws
Bottom cover screw (#8‑32, 5/8‑in, machine) 0261‑ 0013
Bottom cover screw (#4, 3/4‑in, self‑tapping) 0260‑0283
Top
Top cover 0122‑0042
Paper well label 0125‑0259
Window &
buttons
Window 0122‑0018
Buttons 0122‑0005
Window screw with washer (#4, 3/4‑in, self‑tapping) 0261‑0043
Battery eject
button
Push rod 0122‑0009
Rocker arm 0122‑0010
Battery eject button screw (#4‑20, 3/8‑in, self‑tapping) 0261‑0030
Washer 0260‑0228
Battery
contacts
Standoff nut (¼‑in, hex) 0263‑0001
Case contact 0130‑ 0075
Battery contact screw (#2‑56, ¼‑in, machine) 0261‑0007
Printer
Printer 0570‑0092
Printer cable 0600‑ 0131
Hide
Hide 0122‑0008
Printer door 0122‑0006
Hide screws (#4‑40, ¼‑in, machine) 0261‑0008
Overmold
Overmold 0122‑0019
Screws
Overmold screw, back (#8‑16, 3/8‑in, self‑tapping) 0261‑0031
Overmold screw, front (#4‑20, 3/8‑in, self‑tapping) 0261‑0030
PCB
PCB assembly 0141‑0120
EPROM 0752‑0106
Ferrite suppressor 0180‑0140
Screws
PCB screw, medium (#4‑20, 3/8‑in, self‑tapping) 0261‑ 0030
PCB screw, long (#4‑40, 1‑in, machine) 0261‑ 0012
PCB screw, short (#4‑40, ¼‑in, machine) 0261‑0008
LCD
LCD 0230‑0008
LCD standoffs 0264‑0003
LCD standoff nuts 0260‑0264
LCD standoff screws (#4‑40, ¼‑in, machine) 0261‑0008
