30
CONSOLE REPAIR
This section contains instructions for completing service on the BVI3000 console. It consists of the following
procedures:
Disassemble the Console (page32)
Replace the EPROM (page37)
Replace the LCD (page38)
Replace the Window or Buttons (page40)
Service the Printer (page42)
Replace the Battery Contacts (page46)
Replace the Battery Eject Button (page48)
Replace the Top Cover (page51)
Replace the Hide or Printer Door (page53)
Reassemble the Console (page54)
Replace the Console Label (page62)
Program the Console (page65)
Use the procedure Disassemble the Console on page32 in order to disassemble the console to a state
from which you can complete any of the replacement or service procedures. After replacing any damaged
or non‑functioning parts per the procedures in this section, you may skip additional replacement procedures
and go directly to the procedure Reassemble the Console on page54.
The following figure displays the primary parts of the BVI3000 console. For a full list of parts and their
corresponding numbers, see Part Numbers on page87.
