Verathon BladderScan BVI 3000 Service Manual

46
PROCEdURE 14. REPLACE THE BATTERY CONTACTS
QUANTITY PART # DESCRIPTION
Parts
2 0263‑0001 Battery contact standoff nut (¼‑in, hex)
2 0130 ‑0075 Battery case contact
2 0261‑0007 Battery contact screw (#2‑56, ¼‑in, machine)
Tools
AR — Phillips bit
REMOVE THE ORIGINAL BATTERY CONTACTS
1. Complete the procedure Disassemble the Console on page32.
2. Using a Phillips bit, remove the (2) screws securing the battery case contacts in place.
3. Remove the (2) battery case contacts.
4. Flip the top cover over.
5. Remove the (2) hex standoff nuts.
