PowerConnections
Caution
Only use a single power source (PoE, 12V DC or 24V AC). Connecting
multiple different power sources can damage the camera.
Pin 24VAC 12VDC
1 AC_1 Not Applicable
2 AC_2 Not Applicable
3 Earth GND GND
4 Not Applicable 12V DC (+)
Installation
Caution
Verint will not be held liable for damages to persons or property due to the
improper installation of the Nextiva IP cameras.
Cable gland usage is mandatory if you are installing the camera outdoor to
make the cable entry waterproof unless you are using a ¾ inch NPT pipe.
► To install on a surface
1. Loosen the two security screws using the supplied security torx.
2. Remove the dome cover.
3. Attach the supplied alignment sticker to the surface.
4. Drill four pilot holes that are slightly smaller than the anchors into the
surface.
5. Hammer the supplied plastic anchors into the holes.
6. Secure the metal mount plate to the surface with a screwdriver.
Chapter 1: Nextiva V4320Series Overview
© 2014 Verint Systems Inc. All Rights Reserved Worldwide. 15
