Summit & Summit 800
Feature Description and Operation Manual Issue 1.2
353
Web
To activate/deactivate call wait
1. [Call Wait] = ON/OFF (PGM111: Call Wait )
- ON: multiple waiting-call on multiple buttons
- OFF: single waiting-call on single button
To assign a {U-Loop} button:
1. Web admin: [Station Data] => [Flexible buttons] => select ‘U-Loop’ Type and click [SAVE]
button.
2. Keyset : [PGM] + flexible button + Call-coverage numbering plan + My station number.
- Example) 671001 ('67' is call-coverage feature code, '1001' is my station number).
Call Wait Flow
1. One Unified-LOOP(U-LOOP) button can keep one incoming/making/talking/held
internal/external call.
2. An incoming call is acknowledged to be waited if there is an idle Unified-LOOP(U-LOOP)
button. First call to a station is acknowledged even without an idle button. From second
call, there need to be an idle U-LOOP or Station/CO(Grp.)/(CO)LOOP button to accept
the incoming call without reject it to ‘busy’.
3. To make a call, user can dial internal or external number with or without press of the
button.
If user presses a button to make a call then the button will be used for the call.
If user does not press a button then an idle button is automatically seized for the call.
Make of internal call: [button] + dial station number
Make of external call: [button] + co access code + external number
4. Auto-Hold: a talking in a button is automatically sent to being held when press the other
button. Station Data > Common Attributes(111) > Automatic Hold.
5. Auto-Transfer: can transfer a talking call to a new making call by press idle button to
make a call (ex. Operation: user is talking a call => press an empty U-LOOP button and
make a call => complete the transfer by on-hook). Station Data > Common Attributes(111)
> Auto Transfer By Button.
Call Waite Indication
1. Audible Muted Ring (Continuous/One-Burst/Silence by PGM111 Station Data
Programming > “Off-Hook Ring Type”.
2. LCD Display
A. Display Caller Name & Number of Waiting Calls
B. Sequential Display : Talking Call => 1
st
waiting call (for 6 seconds) => 2
nd
waiting call
(for 6 seconds) => … => back to talking call if there is no more waiting call
3. LED Flashing
A. Talking/Making : Green Steady
B. Held : Green Normal-Flash
C. Held Recall : Green Fast-Flash, or Red Fast-Flash to distinguish from 1
st
waiting’
Red Normal-Flash
D. Incoming Waiting :
Single waiting : Amber Normal-Flash
Multiple waiting : 1
st
waiting(Red Normal-Flash), from-2
nd
(Amber Normal-Flash)
E. Differentiation of current LCD displayed Name &Number by LED: Amber Fast-
Flash(for synchronization of Display and Flashing : Amber Fast-Flash button is
