Figure 2-3 Forklift Direction
When transporting each component, the inclination of each equipment should be kept within the range of 80° to 100°,
and should not be excessively tilted, as shown in the Figure 2-4.
Figure 2-4 Carrying obliquity
Notices
1. Always keep the equipment upright and do not leave the equipment outdoors.
2. Use a forklift or pallet truck to ensure that the fork arms (if adjustable) are opened to the widest distance so that they are placed
just below the equipment pallet. Also, make sure the length of the fork arm matches the length of the device.
3. When moving the condenser manually, do not touch the copper tube to avoid bending and deformation of the copper tube and
system leakage.
2.2.2 Installing the Cabinet
1. Unpacking
It is recommended to unpack the cabinet before placing it in the designated site. The steps are as follows:
1) Check the anti-tipping label outside the box before opening the box. If the anti- tipping label is activated (the anti-
tipping label turns red), please contact the staff of Vertiv in time for proper disposal.
2) If you receive the carton packaging, use a utility knife to remove the packaging material, as shown in the
Figure 2-5.
