300mm (12in.) MODELS
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CRV
36"
914mm
TOP VIEW
REAR SIDE
(Liftoff door)
FRONT SIDE
with Display
ACCESS REQUIRED TO SERVICE THE UNIT
BETWEEN EXISTING RACKS WITHIN THE ROW
Front of Unit
C
O
L
D
A
I
R
H
O
T
A
I
R
ONLY Front or Rear
clearance required
ACCESS REQUIRED TO INSTALL THE UNIT
BETWEEN EXISTING RACKS WITHIN THE ROW.
Cooling
System
Height
in. (mm)
Depth
in. (mm)
Install Depth
in. (mm)
Dry Weight,
+/- 5%
lbs (kg)
AIR 507 (230)
WTR/GLY 545 (247)
CW 418 (190)
78-3/4 (2000) 43-5/16 (1100) 49-3/16 (1250
DEPTH
11 13/16"
300mm
HEIGHT OF THE UNIT
FROM THE TOP OF UNIT
TO THE FLOOR
Front of Unit
Install
Depth
Install
Depth
36"
914mm
24"
610mm
12"
305mm
