Figure 6.5 Recommended drycooler installation
ITEM DESCRIPTION ITEM DESCRIPTION
1 Disconnect after charge. Expansion tank
2 Fill water Filling meter
3 Stand-by pump (optional) Gauge
4 Pressure-operated bypass Pump
5 Thermal-management unit Safety valve
Air separator Shut-off valve
Charge group
(filter, reducer, check valve)
Thermostat
Check valve Variex
Drain (at lowest point)
Vertiv | Liebert CRV Installer/User Guide | 55
