12 030624.13
vetus® Electronic engine remote control
4 Command station
Command stations are classified as devices for the control of one or two engines, with or without trim/flap command.
After serial number 18500 there can be mounted in the same installation an unlimited number of command stations,
before serial number 18500 the number of command stations in the same installation is limited to 3; for detailed infor-
mation look at section 7.7.
Depending on the application, it is very important to set the dip-switches present on the bottom part of the command
station, as described in sections 4.4 and 7.6 of this manual.
How to mount the Command Station
Command stations cannot be directly or indirectly mounted onto sources of vibrations. At chapter 17 of this manual you
find the drilling mask drawings.
4.1 Dimensions
4.1.1 Command station EC3
Important: in case the screws to fix command station to the dashboard panel are not long enough, don’t open the com-
mand station to replace them but ask for an adaptation kit.
4.1.2 Command station EC4
C OM M AN D
E NG IN E 2
W AR M /S
E NG IN E 1
132 (5
3
/
16
”)
43
(1
11
/
16
”)
4 x M5
35
(1
3
/
8
”)
20
(
13
/
16
”)
114 (4
1
/
2
”)
174 (6
7
/
8
”)
155 (6
1
/
8
”)
155 (6
1
/
8
”)
100 (3
15
/
16
”)
62 (2
7
/
16
”)
40
(1
9
/
16
”)
25.4 (1”)
114 (4
1
/
2
”)
160 (6
5
/
16
”)
35 (1
3
/
8
”)
75 (2
15
/
16
”)
142 (5
9
/
16
”)
152 (6”)
107.5 (4
1
/
4
”)24.3 (
15
/
16
”)
