Vetus EC3 - Actuator Specifications and Mounting

18 030624.13
vetus® Electronic engine remote control
5 Actuator
With reference to the type of engine and gearboxes, with or without trim/flap, actuators are classified as follow:
• mechanical
• electronic
• mechanical & electronic
It follows the drawings of the different types of actuators. In the last page of this manual you find the footprint of the
actuator in scale 1:2.
5.1 Drawing of actuators with mechanical interface
ø 20
(
3
/
4
”)
213,5 (8
3
/
8
”)
142,5 (5
5
/
8
”)
25
(1”)
300 (11
13
/
16
”)
130 (5
1
/
8
”)
170 (6
11
/
16
”)
200 (7
7
/
8
”)
286 (11
1
/
4
”)
354 (13
15
/
16
”)
390 (15
3
/
8
”)
34°
34°
Shocks absorber
Connectors area
