vetus® Electronic engine remote control
1 Introduction
This manual describes the electronic remote control system in general and its operating, performance and safety aspects.
If it is the first time that you install a VETUS electronic control system, go to the next section where you will be guided to
the necessary steps.
1.1 How to start
Once you have received the system package, follow these steps:
1) identify all the components necessary to build up your system with the help of instructions at sections 4, 5, 6 and
report all the relevant data in the frame here below
2) identify your installation type with the help of section 7.
3) configure the CANBus network, set dip-switches and end of line termination of actuators and command stations, as
described at section 7.6
4) mount command stations and actuators with the help of drilling mask (section 17)
5) make electrical wiring (section 8)
6) install push-pull cables, if your application requires it (section 10)
7) make setting of mechanical strokes, if your application requires it (section 11, 12 and 13)
8) program the actuator specific installation parameters (from section 11 to section 16 included)
9) make the programming of the options, if your application requires it (section 15)
10) once you have set-up the electronic system, read the pilot’s instruction (section 3). Good navigation!
1.2 System configuration and installer remarks
Component Position aboard Serial number
Command station 1
Command station 2
Command station 3
Actuator left engine
Actuator right engine
Boat registration number
Date of installation
Name and signature of
authorized installer
