68 030624.13
vetus® Electronic engine remote control
System with one electronic motor and one gearbox mechanically driven
0L
0F
0H
Gearbox
Push Pull
Problem Solution
The gearbox push-pull cable positions
are inverted
Set A0=3
System with two electronic motors and two gearboxes mechanically driven
Right gearboxLeft gearbox
Push Pull
Push Pull
1L 0L
0F
0H1H
1F
Problem Solution
Positions of the right gearbox are
inverted while the positions of the left
gearbox are correct
Set A0=3
Positions of the left gearbox are in-
verted while the positions of the right
gearbox are correct
Set A0=2
Positions of both gearboxes are invert-
ed
Set A0=1
