Vislink Quantum User Manual

Quantum Receiver User Manual
Specification
Issue No: A Page: 16
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
3. Specification
3.1. Physical & Environmental
Feature
Description
Dimensions
44mm (H) x 430mm (W) x 368mm (L)
(1.7” (H) x 17” (W) x 14.5” (L))
Weight
4.3kg with 2 Demod Cards fitted (build
dependent)
Temperature
0
o
C to 50
o
C (32
o
F to 122
o
F)
Humidity
95% long term
Power Connector
3-pin IEC
Power Supply
100 – 240VAC
Power Consumption
230W (approx., depending on
configuration)
Table 3-1 Physical & Environmental Specification
3.2. RF Parameters
Feature
Description
RF Inputs
4x RF inputs implementing MRC
Diversity reception per demod card
Up to 4x demod cards per unit
Packet switching diversity between
demod cards
Frequency Band
100MHz -1000MHz** Use in conjunction
with the L3025-series down converters.
FEC
1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval
1/32, 1/16, 1/8, 1/4
Frequency Selection
Up to 64 pre-set channels, or tuning in
1MHz steps via front panel control
Demodulation
DVB-T
LMS-T
Demodulation Modes
QPSK, 16QAM, 64QAM
Bandwidth
DVB-T bandwidths of 6/7/8 MHz
LMS-T bandwidths of 3/4/5/6/7/8/10/
12/14/16/20 or 24 MHz with dual
pedestal
Receiver Threshold
Receiver threshold: -92dBm to
BER 10-5 (nom. QPSK)
Table 3-2 RF Parameters Specification
3.3. IP Transport Stream Processing
Feature
Description
IP Inputs
RTP/UDP IP input
Up to 100Mbit/s
SMPTE2022-2 ProMPEG FEC
SRT
IP Outputs
RTP/UDP IP input
Up to 100Mbit/s
SMPTE2022-2 ProMPEG FEC
SRT
Table 3-3 IP Transport Stream Processing Specification
