Quantum Receiver User Manual
Web GUI Screens
Issue No: A Page: 34
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
6.2.4. Active Preset – Selection
The Status>Active Preset panel, displayed in the central panel, displays the
selected configuration preset for the receiver that will be used to process the
received input signals. The settings that have been saved as a configuration
preset are displayed in the right-hand sidebar (see
Section 6.2.5
)
Figure 6-14 Status>Active Preset - Selection
By clicking on the drop-down menu, you can select any of the configuration
presets that have been previously saved.
6.2.5. Active Preset – Configuration Settings (RH Sidebar)
The Active Preset panel, displayed in the right-hand sidebar, displays the
selected configuration preset for the receiver that will be used to process the
received input signals.
Figure 6-15 Status>Active Preset – Configuration Settings
By clicking on the right-hand arrows, the relevant accordion panel will open
and display the detailed settings.
