Chapter 1: Technical parameters
5
Input and output
Input terminals
6 digital inputs
2 analog inputs, one of which supports 0-10V input and the
other supports 0-10V or 4-20mA input.
Output terminals
1 digital output,
1 relay output,
1 analog output terminal, with 0-20 mA /0-10 V output
PTC
Input for PTC protection of the electric motor
LED display
Displays the parameters
Key lock and function
selection
It can block the buttons partially or completely and define
the function range of some buttons to prevent incorrect
function.
Protective mode
Motor short circuit detection at power on, output phase
loss protection, over current protection, over voltage
protection, under voltage protection, over temperature
protection and overload protection.
EMC (Compatibility)
IEC 61000-4-6; IEC 61000-4-4;IEC 61000-4-11;
IEC 61000-4-5
Standards
EN/IEC 61800-3: 2017; C1, which is suitable for the 1st
environment;
EN/IEC 61800-3: 2017; C2, which is suitable for the 1st
environment;
Installation in the
environment
Indoors, avoid direct sunlight, salt, dust, corrosive or
flammable gas, smoke, steam. Resistance to chemical
contamination class 3C3 EN/IEC 60721-3-3. Resistance to
dust contamination 3S3EN/IEC 60721-3-3.
Height above sea
level
Below 1000 meters above sea level (reduce the load level
when using above 1000 meters above sea level)
Ambient
temperature
-10 °C ~ 40 °C (reduce the power level if the ambient
temperature is between 40 °C and 50 °C)
Humidity
Less than 95% relative humidity, non-condensing IEC
60068-2-3
Vibrations
Less than 5.9 m/s2 (0.6 g)IEC 60068-2-6
Storage temperature
-20°C až + 60°C
