Technical data (1001 – 1501)
6 Technical data (1001 – 1501)
6.1 Chassis
Sturdy steel sheet chassis, rubber-mounted engine
6.2 Engine
Engine
Model 1001 up to AC000335 From AB100001H
Models 1501/1501S up to AC000101 From AB150001H/AB150002D
Product Yanmar diesel engine Yanmar diesel engine
Type 3TNE74-NSR3 3TNV76-XNSV
Design Water-cooled 4 stroke diesel engine Water-cooled 4-stroke diesel engine, EPA2
Number of cylinders 3 3
Fuel injection system Direct injection Indirect injection
Aspiration Natural aspiration Natural aspiration
Cooling system Water-cooled Water-cooled/aspirating fan
Lubrication system Force-feed lubrication with trochoidal pump Force-feed lubrication with trochoidal pump
Displacement
1006 cm³ (61.4 in
3
) 1116 cm³ (68.1 in
3
)
Nominal bore and stroke 74 x 78 mm (2.9" x 3.1") 76 x 82 mm (3" x 3.2")
Output
14 kW at 2500 rpm
(18.8 hp at 2,500 rpm)
17 kW at 2500 rpm
(22.8 hp at 2,500 rpm)
Max. torque
63 Nm at 1600 rpm
(46.5 lbf ft at 1,600 rpm)
65.8 Nm at 1600 rpm
(48.5 lbf ft at 1,600 rpm)
Max. engine speed without
load
2500 rpm
1001: 2900 rpm;
1501: 3210 rpm
Idling speed 1100 +/− 25 rpm 1300 +/− 25 rpm
Valve clearance (intake = outlet)
0.15 – 0.25 mm (cold) / (0.0059 – 0.0098 in)
Compression 23.0 : 1 23.5 : 1
Compression: specified value
35 +/− 1 bar at 250 rpm (507 +/− 14.5 psi at 250 rpm)
Compression: threshold
value
27 bar at 250 rpm
(392 psi at 250 rpm)
28 bar at 250 rpm
(406 psi at 250 rpm)
Engine oil pressure under full
load
3 – 4 bar (44 – 58 psi) 3.0 – 4.5 bar (44 – 65 psi)
Pressure switch for engine oil
pump
0.5 +/− 0.1 bar (7.3 +/− 1.5 psi)
Thermostat opens at
69.5 – 72.5 °C (157 – 163 °F)
Thermal switch
107 – 113 °C (225 – 235 °F)
Firing order
1 – 3 – 2
Direction of rotation
Counterclockwise (as seen from the flywheel)
Starting aid
Glow plug (preheating time 10 – 15 sec-
onds)
Glow plugs (preheating time 4 seconds)
Specific fuel consumption 279 g/kWh (0.615 lb/hph) 272 g/kWh (0.599 lb/hph)
Exhaust values according to 97/68/EC EPA Tier II
