Wacker Neuson 2001

6-10 BA 1001/1501/2001 us – Edition 3.3 * * 12001b610.fm
Technical data (1001 – 1501)
6.16 Dimensions model 1501
Fig. 108: Machine dimensions (model 1501)
Main data
Model 1501
Dead weight
1226 kg (2,703 lbs)
Overall height
2550 mm (8'-4'')
Overall height with lowered rollbar
2000 mm (79 in)
Overall height without rollbar
1850 mm (73 in)
Overall width
1305 mm (51 in)
Ground clearance
270 mm (11 in)
Wheelbase
1650 mm (65 in)
Outside turning radius
3300 mm (10'-10'')
