3-24 BA 1001/1501/2001 us – Edition 3.3 * * 12001b330.fm
Operation
Driving on slopes with a loaded skip
Proceed as follows to prevent the machine from tipping over or slipping sideways:
☞When driving on slopes (> 20 %) with a loaded skip, the skip must always face uphill
since the heavier part of the machine – in this case the load in the skip – must face
uphill to prevent the machine from tipping over.
Accident hazard due to tipping over or slipping of the
machine on slopes!
Can cause severe injury or death.
• Travel on slopes only on firm and level ground.
• Do not reverse down slopes.
• Traveling diagonally is prohibited.
Machine travel on slopes with an empty skip
☞When traveling on slopes (> 20 %) with an empty skip, the skip must always face down-
hill since the heavier part of the machine – in this case the engine – must face uphill to
prevent the machine from tipping over.
Machine travel across slopes
☞Do not travel across slopes with lateral inclinations steeper than 20 %!
☞When traveling across slopes with lateral inclinations up to 20 %, tilt out the skip only
uphill for stability reasons.
Accident hazard due to tipping over or slipping of the
machine on slopes!
Can cause severe injury or death.
• Machine travel across slopes (max. inclination up to 20 %) is allowed only on
firm ground.
Fig. 40: Driving on slopes with a loaded skip
> 20 %
Fig. 41: Driving on slopes with an empty skip
> 20 %
