3-16 BA 1001/1501/2001 us – Edition 3.3 * * 12001b330.fm
Operation
StVO accessories (option)
Scope of delivery of StVO accessories:
• Headlights and rear lights
• Turn indicators and clearance lights
• Reversing light and reflectors
• Numberplate console and light
• Wheel chock
• Control lever lock
Reversing signal (option)
The reversing signal sounds during backward machine travel.
Accident hazard when traveling forward/backward!
Crushing hazard causing death or severe injury.
• Do not allow anyone to stay in the danger zone.
• Do not rely on the reversing signal under any circumstances.
• If the reversing signal does not sound, stop machine operation immediately
and get in touch with a Wacker Neuson service center (observe the relevant
national regulations).
Before starting the engine
☞Adjust your seating position – see Seat adjustment on page 3-27
All controls must be within easy reach. You must be able to press the acceler-
ator and brake pedals to their limit positions!
☞Fasten your seat belt – see Seat belt on page 3-28
☞Check whether all levers and pedals are in neutral position
☞Press the accelerator pedal to the center position (between minimum and maximum) if
the engine is cold
General information on starting the engine
The model 1001 and 1501 engine will not start unless the parking brake is
applied and the brake pedal is pressed at the same time.
• 1001: from serial no. EA03289.
• 1501: from serial no. WNCD0105TPAL00166.
• Besides, the starter cannot be actuated if:
• the engine is already running (start repeat interlock),
• the travel lever is not in neutral position,
• the parking brake is not applied.
➥1001: up to serial no. EA03288.
➥1501: up to serial no. WNCD0105TPAL00165.
• the parking brake is not applied (2001).
