Wacker Neuson 2001

BA 1001/1501/2001 us – Edition 3.3 * 12001b610.fm 6-11
Technical data (1001 – 1501)
6.17 Dimensions model 1501S
Fig. 109: Machine dimensions (model 1501S)
Main data
Model 1501S
Dead weight
1210 kg (2,668 lbs)
Overall height
2550 mm (8'-4'')
Overall height with lowered rollbar
2000 mm (79 in)
Overall height without rollbar
1850 mm (73 in)
Overall width
1305 mm (51 in)
Ground clearance
270 mm (11 in)
Wheelbase
1700 mm (67 in)
Outside turning radius
3300 mm (10'-10'')
