Wacker Neuson 2001 User Manual

1-10 BA 1001/1501/2001 us – Edition 3.3 * * 12001b110.fm
Introduction
1.11 Other signs and symbols
Important
Type, quantity and position of the labels depend on options, country and machine.
The following states signs and symbols that do not contain explanatory text and that are
not explained in the following chapters.
Short model designations
☞1501 swivel skip = 1501S
☞1501 high-tip skip = 1501H
Meaning
Raise the machine or machine parts only by means of these eyelets.
Position
At the lifting eyes.
Meaning
Machine runs with diesel fuel. Add diesel fuel only!
Position
On the fuel tank
Meaning
Reservoir contains hydraulic oil
Position
On the hydraulic oil reservoir
Fig. 6: Lifting eye
Fig. 7: Fuel tank
Fig. 8: Hydraulic oil reservoir
