BA 1001/1501/2001 us – Edition 3.3 * 12001b510.fm 5-9
Maintenance
Replacing the fuel filter
Use a suitable container to collect fluids and lubricants as they flow out and
dispose of them in an environmentally friendly manner.
Removing the fuel filter (D)
☞Close fuel cock B
☞Loosen union nut A
Caution: the filter housing contains fuel.
☞Remove filter housing C
Installing the fuel filter (D)
☞Install all elements in the reverse order with a new filter element
☞Open the stop cock on the water separator again
☞Bleed the fuel system – see Bleeding the fuel system on page 5-7
☞Make a test run – and check for tightness!
☞Dispose of the old fuel filter cartridge by an ecologically safe method
Fig. 80: Fuel filter 1001/1501
Off
On
C
B
A
Fig. 80: Fuel filter 2001
D
