4-52 BA 357-00 * 3.0 * 35700_04_Inbetriebnahme_03.fm
4 Putting into operation
Functional check of all control elements
• – see chapter 5 “Checking the steering system” on page 5-1
• – see chapter 5 “Service brake” on page 5-5
• – see chapter 5 “Lighting /signaling system” on page 5-19
• – see chapter 5 “Operating hydraulics” on page 5-30
Raising the attachment to transport position
Remove buckets/attachments that are not certified for machine travel on
public roads, and move or transport them with a suitable means of
transportation
– see "Attachments for KRAMER quickhitch facility" on page 3-18,
Attachments for SKID STEER quickhitch (currently not available) on
page 3-21 or
Attachments for EURO quickhitch on page 3-23.
Loader unit operation
– see chapter 5 “Operating hydraulics” on page 5-30.
Example of certified bucket:
1. Empty and tilt back the bucket B.
2. Raise the loader unit until both red marks D on the lift frame and the
bulkhead are aligned.
➥ Ground clearance C about 250 mm (9.84 in).
3. Cover the blade or teeth of the bucket across their entire width with the
tooth guard A provided.
4. Secure the joystick
– see "Locking/unlocking the control lever (joystick)" on page 4-51.
5. Lock the 3rd control circuit
– see "Locking/unlocking the 3rd control circuit" on page 4-51.
