BA 357-00 * 3.0 * 35700_05_Bedienung.fm 5-41
Operation 5
Important information on operation of the 3rd control circuit
The 3rd control circuit hydraulically locks the attachment in the quickhitch
and secures it against unintentional unlocking.
By changing over the flexible lines on the hydraulic attachment (for
example a multipurpose bucket), it can be operated with the 3rd control
circuit – see "Control lever (joystick) overview" on page 5-32.
The 3rd control circuit can also be operated with the “Continuous
operation“ option
– see "Continuous operation of 3rd control circuit" on page 5-44.
Accident hazard due to unlocked attachment on the quickhitch!
The attachment can come off the quickhitch unexpectedly and cause
serious injury or death.
► Ensure that the attachment is visibly locked on either side with the lock
pins E of the quickhitch.
To lock attachments to the quickhitch
– see "Locking the attachment" on page 5-42!
Fig. 132
E
E
KRAMER
SKID STEER
E
EURO
