5 Operation
Operation of 3rd control circuit
Locking the attachment
1. Pick up the attachment – see "Attachment on KRAMER quickhitch" on
page 5-56, Attachment on SKID STEER quickhitch (opt) on page 5-61
or Attachments for EURO quickhitch (optional) on page 5-65.
2. Lock the attachment. Press the rocker switch 52 on
the joystick to the left.
➥ The attachment is locked in the quickhitch.
➥ Attachment is secured against unintentional unlocking.
3. During machine travel on public roads, lock the 3rd control circuit.
To do this: slide the lock in toggle switch 72 downward and press the
toggle switch to position A.
➥ Indicator display C/1 in the digital display in the gauge extinguishes.
➥ The 3rd control circuit is locked.
➥ Switch on the joystick is not functional.
