5-56 BA 357-00 * 3.0 * 35700_05_Bedienung.fm
5 Operation
Attachment on KRAMER quickhitch
Important information on locking the attachment
The attachment locked onto the quickhitch is secured against
unintentional operation of switch on the joystick. The attachment can only
be unlocked from the quickhitch by means of the two-hand controls
– see "Removing an attachment from a SKID STEER quickhitch" on
page 5-64.
Accident hazard due to attachments incorrectly locked in the
quickhitch!
Can cause serious injury or death.
► Regularly check lock pin G, mounting bore L and limit M of the
attachment for damage.
► Have damaged parts immediately replaced by an authorized service
center.
► Only lock and unlock empty attachments without any load.
► Ensure that the attachment is visibly locked on
either side with lock pins E.
