Wacker Neuson KRAMER 5055e User Manual

BA 357-00 * 3.0 * 35700_07_Wartung.fm 7-43
Maintenance 7
Installation
1. Carefully approach the battery tray with pallet forks from behind as far
as possible until stopped on the rear of the machine. Pay attention that
the battery tray engages in the front clamp.
2. Driving in reverse, carefully draw the pallet forks backwards out of the
supports B on the battery tray.
3. Align the battery tray.
4. Insert the retaining bolts A with sleeves and screw them in.
5. Tighten hexagon nuts to 195 Nm (144 ft lb).
Fig. 227
B
A
Fig. 228
A
