8-4 BA 357-00 * 3.0 * 35700_08_Betriebsstörung.fm
8 Malfunctions
Description of indications in display
The machine electronics save the active and passive errors.
• Active errors are immediately displayed in the gauge display in field 45
F/3 when the error occurs.
• Passive errors are not displayed when the error occurs. Passive errors
are only displayed during queries of the error
memory in the service display.
The error code is saved in the error memory as a passive error
if it is no longer displayed after turning the machine off and on again.
When calling up the error messages, first the active and then the passive
errors are displayed. If multiple error messages in a category are present,
these can be called up one after the other in the display. The error
messages are displayed in the order of their occurrence.
Calling up error messages
The following conditions must be fulfilled for querying the error memory:
• The machine must be at a standstill.
• The ignition key in position 1.
• Forward-reverse control in position "neutral".
If a travel direction is selected when querying an error, the display returns
to the main display.
1. Press the push button 47 in order to call up the service display.
➥ The startup screen displaying the number of hours until the next
inspection is displayed in the display.
2. Press the push button Taster 46 in order to call up the saved error
message or the scroll one page down in the digital display within the
error display.
➥ If no error messages are present, no numbers will be shown on the
first page that is called up.
