4-18 BA 357-00 * 3.0 * 35700_04_Inbetriebnahme_01.fm
4 Putting into operation
Adjusting the mirror on the right
1. Turn the mirror on the right outward with the long side.
When making preliminary adjustments, ensure that the mirror bracket
is turned far enough to the front (about 45°) to avoid touching
the door window.
2. Adjust the rearview mirror on the right:
- The outer edge of the machine must be visible on
the inside X of the mirror.
- The horizon must be visible at the upper edge Y.
- At the lower edge Z, the visible area of the road must be as
close as possible to the machine.
