W&T Com-Server++ - Page 106

106
W&T Mode TCP client
Example 1: A control program polls a measuring device; the
measuring device is passive
A B
serial connection
Intranet /
Internet
Configuration menu:
r TCP/IP Mode r TCP-Client
Com-Server A
- Server Port: 8000
- Server IP: IP address Com-Server B
- Client“C“+Addr.: deactive
Com-Server B
- Server Port: 0000
- Server IP: 0.0.0.0
- Client“C“+Addr.: deactive
Example 2: A control program polls a measuring device; the
measuring devicve can actively send data to the control pro-
gram
A B
serial connection
Intranet /
Internet
Configuration menu:
r TCP/IP Mode r TCP-Client
Com-Server A
- Server Port: 8000
- Server IP: IP address Com-Server B
- Client“C“+Addr.: deactive
Com-Server B
- Server Port: 8000
- Server IP: IP address Com-Server A
- Client“C“+Addr.: deactive
