Optional Add-on Timer = 60ms

Optional Add-on Timer = 70ms

DEFAULT

Optional Add-on Timer = 100ms

Optional Add-on Timer = 120ms

Optional Add-on Timer = 140ms

Optional Add-on Timer = 160ms

Add-Ons ENTER/EXIT PROGRAMMING MODE

98

WLS9600

Optional Add-On Timer (continued)
