Data Editing
Product Reference Guide
247
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-
0xFF), used to identify a barcode (symbology) type. It can be appended previous to or following
the transmitted barcode data depending upon how this option is enabled. This feature provides
options for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-loaded Sets"
below) or individually per symbology (see "Label ID: Set Individually Per Symbology"on
page 249). If you wish to program the reader to always include an
industry standard label
identifier for ALL symbology types, see "Global AIM ID"on page 53.
Label ID: Pre-loaded Sets
The reader supports two pre-loaded sets of Label IDs. Table 38 shows the USA and the EU sets.
CAUTION
When changing from one Label ID set to another, all other reader configu-
ration settings, including the host interf
ace type, will be erased and set to
the standard factory defaults. Any custom configuration or custom defaults
will be lost.
Table 38. Label ID Pre-loaded Sets
Symbology USA Label ID set EU Label ID set
ASCII
character
Hexidecimal
value
ASCII
character
Hexidecimal
value
ABC Codabar S 530000 S 530000
Anker Plessey o 6F0000 o 6F0000
CODABAR % 250000 R 520000
Codablock F l 6C0000 m 6D0000
CODE11 CE 434500 b 620000
CODE128 # 230000 T 540000
CODE32 A 410000 X 580000
CODE39 * 2A0000 V 560000
CODE39 CIP Y 590000 Y 590000
CODE4 4 340000 4 340000
CODE5 j 6A0000 j 6A0000
CODE93 & 260000 U 550000
CHINA POSTAL CODE s 730000 s 730000
EAN13 F 460000 B 420000
EAN13 P2 F 460000 L 4C0000
EAN13 P5 F 460000 M 4D0000
EAN13 P8 F 460000 # 230000
