USB Keyboard Speed = 7ms

USB Keyboard Speed = 8ms

USB Keyboard Speed = 9ms

USB Keyboard Speed = 10ms

ENTER/EXIT PROGRAMMING MODE

44

WLS9600

USB Keyboard Speed (continued)

USB Keyboard Numeric Keypad

This option Controls whether numeric characters will be sent using standard keys or the

numeric keypad.

DEFAULT

Standard Keys

Numeric Keypad
