ENTER/EXIT PROGRAMMING MODE

20

WLS9600

Baud Rate

See page 231 for information on this feature.

Baud Rate = 1200

Baud Rate = 2400

Baud Rate = 4800

Baud Rate = 9600

DEFAULT

Baud Rate = 19,200

Baud Rate = 38,400

Baud Rate = 57,600

Baud Rate = 115,200
