ENTER/EXIT PROGRAMMING MODE

38

WLS9600

Numlock

This option specifies the setting of the Numbers Lock (Numlock) key while in keyboard wedge

interface. This only applies to alternate key encoding interfaces. It does not apply to USB

keyboard.

DEFAULT

Numlock = Numlock key unchanged

Numlock = Numlock key toggled
