Product Reference Guide

275

Appendix C

Sample Barcodes

The sample barcodes in this appendix are typical representations for their symbology types.

1D Barcodes

UPC-A

EAN-13

978033029095

Code 39

Code 128

Code 128

Interleaved 2 of 5
