Figure 3–9: Chart mark connections to a manual injector
Figure 3–10: Inject start connections to a manual injector
Detector
connector A
Manual
injector
1 + Inject Start
2 - Inject Start
3 Ground
4 + Purge
5 - Purge
6 + Polarity
7 - Polarity
8 Ground
9 + Chart Mark
10 - Chart Mark
11 Ground
12 + Switch
13 - Switch
Detector
connector A
Manual
injector
1 + Inject Start
2 - Inject Start
3 Ground
4 + Purge
5 - Purge
6 + Polarity
7 - Polarity
8 Ground
9 + Chart Mark
10 - Chart Mark
11 Ground
12 + Switch
13 - Switch
