November 16, 2016, 715004521 Rev. C
Page 58
Figure 5–17: Core 1 configuration with a PDA, TQ-XS, and splitter
The following table describes final tubing connections and does not list factory-installed tubing
connections.
PDA
CM-A
MS splitter
mounted to
CM-A
Solvent
tray
TQ-XS
515 makeup pump
ccManager
SM-FL
ccBSM
Pump
control
module
1
2
3
4
