Figure 5–30: Core 4 configuration with a PDA, ELSD, ISM, and QDa
The following table describes final tubing connections and does not list factory-installed tubing
connections.
Table 5–15: Core 4 configuration with a PDA, ELSD, ISM, and QDa
Tube
Tube
description
From To ID
Notes:
recommended
trim length
1 60.0 inch
PEEK tubing
ISM splitter
module
ccManager vent
valve tee
0.007 inches Optional trim up
to 30 inches
228inch
PEEK tubing
CM-30S or PDA ISM splitter
module
0.007 inches Trim to
15 inches
331inch
PEEKsil tubing
ISM splitter
module
ELSD 75 μmN/A
4 Probe ISM splitter QDa probe N/A N/A
Solvent tray
ELSD
PDA
ISM with
UPC2
splitter
QDa
CM-30S
ccManager
SM-FL
ccBSM
4
2
1
3
ISM
splitter
module
