Chapter 3: Installing Power, Surge Protection, and Communications
•
19
3
Installing Power, Surge
Protection, and Communications
How you install power, surge and communication modules varies
based on what enclosures you use and where they’re located.
Installations with a pole-mount box only
This is where the sensor cable runs down the pole to the pole-
mount box and to nowhere else. Power comes from solar, a battery,
or a power line that runs straight to the pole; communications are
wireless or use a comms line that runs straight to the pole.
Figure 12. Installation with pole-mount box and no cabinet
Warning. We strongly
recommend you
follow the guidelines
in this chapter,
especially as they
relate to surge
protection. Failure to
properly protect your
sensors from surges
will void the sensor
warranty. If you need
more information,
contact support@
wavetronix.com.
