SmartSensor HD User Guide
Setting Description Details
Range & Width Shows the size and
placement of the
lanes (Range refers to
the distance from the
sensor).
Can’t be changed.
Hide Auto Lanes Hides (but does
not delete) the
automatically
configured lanes from
the edit area.
This can also be done
through the View
menu.
Capture Saves the lane
you clicked on
to the sensor’s
configuration.
When captured,
the lane will turn
from blue to black.
This can also be
done by clicking
on the automatic
configuration sidebar.
Exclude Tells the sensor to
ignore the lane;
detections in the lane
won’t affect alignment
or configuration.
To include the area
again, click it to open
the Excluded Area
window and click
Include.
An excluded lane
behaves like a
deleted lane; the
difference is that an
excluded lane can
easily be included
again, while a deleted
lane will have to be
reconfigured. An
excluded area will
turn red.
