Wavetronix SmartSensor HD - Verifying lanes using vehicle display options

74
•
SmartSensor HD User Guide
Figure 71. Verification screen
Verification options
Sidebar button
Play/pause/stop buttons
Per Vehicle Data
Sidebar
Vehicle Display menu
Vehicle Display menu
Figure 72. Lane verification tools
Verifying lanes means comparing the detection data in the SSMHD
software with the actual trac in the roadway; you can observe
the roadway trac yourself, or record it using a separate device. If
the actual trac matches the software trac, your lanes are set up
properly.
