Wecon VD2F-010SA1P - Page 14

Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
8
The 220V power supply specifications and 380V power supply specifications of the VD2B drive have
the same appearance and composition.
Opera on panel
High voltage indicator
CN 1: Encoder connector
C 2: connectorCo ntrol in put and output
Ground screw
M ain p ow er connector
L1
L2
P+
C
D
N
M otor outpu t connector
U
V
W
PE
C 4: H ost com puter RS422 com mun ica on
port or RS485 com m unica on po rt
C 3: H ost com puter RS422 com mun ica on
port or RS485 com m unica on po rt
N
N
N
Figure 2-7 Composition of VD2F servo drive
Figure 2-8 Short connection of braking resistor
