3.2.2 Installation site
1
Do not use the motor near corrosive, flammable gas environment, combustible materials such
as hydrogen sulfide, chlorine, ammonia, sulfur, chlorinated gas, acid, alkali, salt, etc.
2
Do not remove the oil seal in places where there is grinding fluid, oil mist, iron powder, cutting,
etc.
3
Do not use the motor in a closed environment. Closed environment will cause high
temperature of the motor and shorten the service life.
4
A place far away from heat sources such as stoves.
3.2.3 Installation environment
The installation environment of the servo motor has a direct impact on the normal function of it
and its service life. Therefore, the installation environment of the servo motor must meet the
following conditions:
Item
Specification
Ambient temperature
-10℃ to 40℃ (no freezing)
Ambient humidity
-20% to 90%RH (non-condensing)
Storage temperature
-20℃ to 60℃
Storage humidity
-20% to 90%RH (non-condensing)
Protection grade
IP65
Vibration
Less than 0.5G (4.9m/s2), 10 to 60Hz (non-continuous operation)
3.2.4 Installation precautions
Item
Specification
Rust inhibitor
Before installation, please wipe clean the “rust inhibitor” on the shaft
extension end of the servo motor, and then do the relevant anti-rust
treatment.
Encoder notice
✎When installing a pulley on a servo motor shaft with a keyway, use a
screw hole at the shaft end. In order to install the pulley, first insert the
double-headed nail into the screw hole of the shaft, use a washer on the
surface of the coupling end, and gradually lock the pulley into the pulley
with a nut;
✎For the servo motor shaft with keyway, use the screw hole on the shaft
end to install;
✎For shafts without keyway, friction coupling or similar methods are used;
✎When removing the pulley, use a pulley remover to prevent the bearing
from being strongly impacted by the load;
✎To ensure safety, install a protective cover or similar device in the
rotating area, such as a pulley installed on the shaft.
Centering
When linking with the machine, please use the coupling, and keep the axis
of the servo motor and the axis of the machine in a straight line.
Installation
direction
The servo motor can be installed horizontally or vertically.
Oil and water
counter measures
When using in a place with dripping water, please use it after confirming
the protection level of the servo motor. When using it in a place where oil
drips on the shaft penetration part, do not remove the oil seal of the servo
motor.
The use conditions of the servo motor with oil seal:
