4.4 Servo drive control input and output wiring
4.4.1 CN2 pin distribution
(1) VD2A and VD2B servo drive control input and output pin distribution (CN2 interface)
1
16
31
30
15
H44
Figure 4-9 VD2A and VD2B servo drive control input and output pin distribution
Pin number
Signal name
Pin number
Signal name
Pin number
Signal name
1
-
16
GND
31
-
2
AI_2+
17
GND
32
AI_1+
3
AI_2-
18
-
33
AI_1-
4
DO1-
19
DO3-
34
GND
5
DO1+
20
DO3+
35
-
6
DO2-
21
DO4-
36
-
7
DO2+
22
DO4+
37
-
8
SS
23
DI5
38
-
9
DI1
24
DI6
39
-
10
DI2
25
DI7
40
SIGN-
11
DI3
26
DI8
41
SIGN+
12
DI4
27
GND
42
PULS-
13
PAO-
28
PAO+
43
PULS+
14
PBO-
29
PBO+
44
PL
15
PZO-
30
PZO+
--
--
Table 4-12 CN2 interface definition of VD2A and VD2B servo drive
